References#
The following references apply when reading AGTTM9: 21.
| Reference to… | Means |
|---|---|
| AGTTM09-21 | Austroads Guide to Temporary Traffic Management Part 9: Sample Layouts, as amended by this document: for example, a reference to AGTTM09-21 means you must refer to the Queensland Guide to Temporary Traffic Management (QGTTM) Part 9. Throughout AGTTM09-21, references are made to other parts of the Guide (for example, when reading Part 9 you may be referred to Part 3 for further information.) In this case, you must refer to the equivalent Part within the QGTTM. Check the applicability of the equivalent Part in the QGTTM before referring to the referenced Austroads Guide Part. |
| AGTTM | Austroads Guide to Temporary Traffic Management |
| AS 1742 | Australian Standard AS 1742 Manual of Uniform Traffic Control Devices |
| Queensland (Q) series / Traffic Control (TC) signs | MUTCD (Q) series and TC signs. |
| Queensland MUTCD | Queensland Manual of Uniform Traffic Control Devices which supplements AS 1742. |
Table in words
- For Reference to… AGTTM09-21, the Means is: Austroads Guide to Temporary Traffic Management Part 9: Sample Layouts, as amended by this document: for example, a reference to AGTTM09-21 means you must refer to the Queensland Guide to Temporary Traffic Management (QGTTM) Part 9.
- Throughout AGTTM09-21, references are made to other parts of the Guide (for example, when reading Part 9 you may be referred to Part 3 for further information.)
- In this case, you must refer to the equivalent Part within the QGTTM.
- Check the applicability of the equivalent Part in the QGTTM before referring to the referenced Austroads Guide Part.
- For Reference to… AGTTM, the Means is: Austroads Guide to Temporary Traffic Management.
- For Reference to… AS 1742, the Means is: Australian Standard AS 1742 Manual of Uniform Traffic Control Devices.
- For Reference to… Queensland (Q) series / Traffic Control (TC) signs, the Means is: MUTCD (Q) series and TC signs.
- For Reference to… Queensland MUTCD, the Means is: Queensland Manual of Uniform Traffic Control Devices which supplements AS 1742.
Relationship table (harmonised to AGTTM09-21 Edition 1.1)#
| Section | Description | Applicability |
|---|---|---|
| 1 | Introduction | |
| 1.1 | Purpose | Accepted |
| 1.2 | Structure of AGTTM | Accepted |
| 1.3 | Scope | Accepted |
| 1.4 | Application of Part 9 to New Zealand | Accepted |
| 1.5 | Definitions | Accepted |
| 2 | Sample Layouts | |
| 2.1 | Objectives | Accepted |
| 2.2 | Sample Layout Content and Structure | Accepted |
| 3 | Summary of Scenarios | |
| 3.1 | Static Worksites (AGTTM Part 3) | Accepted |
| 3.1.1 | Around worksites | Accepted |
| 3.1.2 | Through worksites | Accepted |
| 3.1.3 | Past worksites | Accepted |
| 3.1.4 | Worksites at roundabouts | Accepted |
| 3.2 | Mobile Works (AGTTM Part 4) | Accepted |
| 3.2.1 | Mobile works | Accepted |
| 3.2.2 | Works on unsealed roads | Accepted |
| 3.3 | Short Term or Low Impact Work Sites (AGTTM Part 5) | Accepted |
| 3.3.1 | Works on road | Accepted |
| 3.3.2 | Works outside of traffic lane | Accepted |
| 3.4 | Worked Examples | Accepted |
| Appendices | ||
| A | Sample Layouts (Around Worksites) | Accepted |
| B | Sample Layouts (Through Worksites) | Accepted |
| C | Sample Layouts (Past Worksites) | Accepted |
| D | Sample Layouts (Worksites at Roundabouts | Accepted |
| E | Sample Layouts (Mobile Works) | Accepted |
| F | Sample Layouts (Work on Unsealed Roads) | Accepted |
| G | Sample Layouts (Short Term Low Impact – Works on Roads) | Accepted |
| Section | Description | Applicability |
|---|---|---|
| H | Sample Layouts (Short Term Low Impact – Works off Roads) | Accepted |
| I | Sample Layouts (Worked Examples) | Accepted with amendments |
Appendix I: Sample Layouts (Worked Examples)#
Addition
Add the following to the Design Considerations, note 4 in Sample Layout 40 Title block, notes and certification. The TMP and TGS(s) must be signed and dated by the person that designed it. This signature may be electronic.
Difference
The following sample layout is not accepted in Queensland:
- Sample Layout 42 Application of AGTTM Part 3 Figure 5.1.
Addition
For worked examples and guidance on developing Traffic Guidance Schemes in Queensland, refer to Technical Note 195 Traffic Guidance Schemes worked examples.
