4Quality system requirements#
The quality system requirements defined in MRTS201 General Equipment Requirements apply to this Technical Specification. Additional quality system requirements relevant under this Technical Specification are defined in Table 4.1.
4.1Hold Points, Witness Points and Milestones#
General requirements for Hold Points, Witness Points and Milestones are specified in Clause 5.2 of MRTS01 Introduction to Technical Specifications.
The Hold Points, Witness Points and Milestones applicable to this Technical Specification are summarised in Table 4.1. There are no Milestones defined.
| Clause | Hold Point | Witness Point | Milestone |
|---|---|---|---|
| 4.2 | 1. Detailed design documentation to be provided prior to manufacture 2. Optical performance certification | ||
| 5.4 | 3. Safety requirements | ||
| 6.2.1 | 4. Vehicle, Trailer and/or concrete block support structure design documentation | ||
| 11.8 | 1. Optical Performance Test | ||
| 13 | 2. Factory Acceptance Test |
4.2Samples for acceptance#
The requirements of MRTS201 General Equipment Requirements apply to this Technical Specification. Detailed designs of the sign layout, fabrication and assembly drawings, calculations, specifications and certifications of the TVMS components (signed by the Contractor’s RPEQ) shall be submitted to the Principal for verification prior to manufacture. These components include the TVMS controller, sign face, LEDs, LED matrix boards, pixel arrangements showing horizontal and vertical pitch and total number of pixels, power supply (including solar power, surge protection and backup batteries), communication ports, cable termination, enclosure and mounting accessories. Hold Point 1
Optical performance test methodology and National Association of Testing Authorities (NATA) or NATA-accredited or NATA-endorsed by Mutual Recognition laboratory certification confirming the TVMS performance requirements specified in this Technical Specification must be submitted before delivery to site. Hold Point 2
4.3Warranty#
The Contractor installing the TVMS shall warrant the installation against defects for a minimum of 5 years in accordance with the requirements of MRTS201 General Equipment Requirements.
