Front matter#
| 1600 200 Joining 400 edge 200 0 R25 214 198 198 198 198 4 1 0 4 1 198 198 198 Stiffener rails 75 Joining edge 75 50 Back panel arrangement Colour Legend Notes Black 1. This sign is used for new sight board installations where two D4-1-1-Q03 unidirectional hazard markers may be used. 2. Sight board installation and connection details are shown in SD1452. Retroreflective white 3. Utilise D4-1-1-Q03 with type 1 stiffener rails only. Type 2 stiffener rails are not permitted. | ||
| SIGHT BOARD | ||
| Department of Transport and Main Roads Infrastructure Management & Delivery Division | APPROVED AS OFFICIAL TRAFFIC SIGN 24/05/18 PRINCIPAL ENGINEER Date (Traffic Engineering) | D4-1-1-Q03 |
| Designed RH 05/18 | Checked DS 05/18 | Scale Not to Scale |
| A | ||
| 4 6 6 1 6 4 6 1 4 6 6 4 1200 1200 45° 45° R20 R20 150 150 D4-3-Q01(L) D4-3-Q01(R) Colour Legend Note: This hazard marker may be used where both delineation and hazard marking may be advantageous and Black where limited space is available to install a standard D4-3 Retroreflective white hazard marker. | ||
| WIDTH MARKER NARROW OPTION - (L&R) | ||
| Department of Transport and Main Roads Infrastructure Management & Delivery Division | APPROVED AS OFFICIAL TRAFFIC SIGN 27/8/19 PRINCIPAL ENGINEER Date (Traffic Engineering) | D4-3-Q01 |
| Designed RH 08/19 | Checked DJ 08/19 | Scale Not to Scale |
| A |
Table in words
- The table row contains 1600 200 Joining 400 edge 200 0 R25 214 198 198 198 198 4 1 0 4 1 198 198 198 Stiffener rails 75 Joining edge 75 50 Back panel arrangement Colour Legend Notes Black 1. This sign is used for new sight board installations where two D4-1-1-Q03 unidirectional hazard markers may be used. 2. Sight board installation and connection details are shown in SD1452. Retroreflective white 3. Utilise D4-1-1-Q03 with type 1 stiffener rails only. Type 2 stiffener rails are not permitted.
- The table row contains SIGHT BOARD.
- The table row contains Department of Transport and Main Roads Infrastructure Management & Delivery Division, APPROVED AS OFFICIAL TRAFFIC SIGN 24/05/18 PRINCIPAL ENGINEER Date (Traffic Engineering), D4-1-1-Q03.
- The table row contains Designed RH 05/18, Checked DS 05/18, Scale Not to Scale.
- The table row contains A.
- The row contains: 4 6 6 1 6 4 6 1 4 6 6 4 1200 1200 45° 45° R20 R20 150 150 D4-3-Q01(L) D4-3-Q01(R) Colour Legend Note: This hazard marker may be used where both delineation and hazard marking may be advantageous and Black where limited space is available to install a standard D4-3 Retroreflective white hazard marker.
- The row contains: WIDTH MARKER NARROW OPTION - (L&R).
- The row contains: Department of Transport and Main Roads Infrastructure Management & Delivery Division; APPROVED AS OFFICIAL TRAFFIC SIGN 27/8/19 PRINCIPAL ENGINEER Date (Traffic Engineering); D4-3-Q01.
- The row contains: Designed RH 08/19; Checked DJ 08/19; Scale Not to Scale.
- The row contains: A.
ADVISORY SPEED CHEVRON ALIGNMENT MARKER (L & R) - LARGE
| a | b | c | d | e | f | g | h | k | m | n | o | r | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 3000 | 750 | 90 | 100Em | 120 | 320D | 750 | 270 | 20 | 30 | 345 | 345 | 50 |
| B | 3600 | 900 | 108 | 120Em | 146 | 380D | 900 | 324 | 24 | 36 | 414 | 414 | 60 |
| C | 4500 | 1125 | 135 | 150Em | 180 | 480D | 1125 | 405 | 30 | 45 | 517 | 518 | 75 |
Colour Legend Black Retroreflective yellow
Department of Transport and Main Roads Infrastructure Management & Delivery Division APPROVED AS OFFICIAL TRAFFIC SIGN 17/10/23 PRINCIPAL ENGINEER Date (Traffic Engineering) D4-7-Q01 Designed RH 10/23 Checked JP 10/23 Scale Not to Scale A
