4.8Detour signs#
4.8.3DETOUR (T5-1, TM5-1)#
Addition
Add the following rows to Table 4.3(C):
| Sign | Sign number | Size, mm |
|---|---|---|
| DETOUR (U-Turn) | TM5-1-Q01 | DETOUR (U-Turn) |
| Detour (U-Turn) Symbolic | TM5-1-Q02 | 600 x 600 |
| U-TURN FACILITY AHEAD | TM5-1-Q03 | 600 x 600 |
Addition
For detour routes that include a U-turn requirement, the DETOUR U-turn (TM5-1-Q01), Detour U-turn (symbolic) (TM5-1-Q02), or the U-TURN FACILITY AHEAD (TM5-1-Q03) signs may be used.
The Detour U-turn (symbolic) (TM5-1-Q02) panel shall only be used with a DETOUR panel (TM5-7A or TM5-7B).
TM5-1-Q01 TM5-1-Q02 TM5-1-Q03
4.8.4Detour marker (T5-6, TM5-6A)#
Addition
When the Detour marker (TM5-6A) is used in a multi-message arrangement, the arrow panel should be located as follows:
- For an arrow pointing straight-ahead, locate the arrow closest to traffic, except where other direction related symbol panels (such as no right turn) are required in this location.
- For an arrow indicating a turn to the left or right, locate the arrow on the side of the multi-message arrangement the arrow is directing towards.
